WideAnt2-5G™ True MIMO Dual Antenna for Routers Hotspots Modems Ultra-Wide Band Directional High-Gain Antenna Set 5G/4G/3G/2G 450 to 6000 MHz

The WideAnt2-5G™ by WirEng® was the first ever consumer-oriented, fully 5G MIMO antenna in the worldwide market when it first launched in January 2019. The WideAnt2-5G™ by WirEng® is a truly ultra-wide band, MIMO, directional, high-gain antenna fully supporting all 5G/4G/3G/2G bands worldwide. The WideAnt2-5G™ by WirEng® is also fully enclosed into anti-UV, thick acrylonitrile-butadiene-styrene plastic for flawless operation under all weather conditions, and it also possesses an ultra-low reflection coefficient, with a VSWR of only 1:1.0 to 1:1.5 over it's full range of 450 MHz to 6000 MHz. The WideAnt2-5G™ by WirEng® uses 24k gold, stainless steel, and copper, and has on-radome N-type, fully gold-plated connectors for maximum reliability, durability, and RF power transfer. The WideAnt2-5G™ by WirEng® is a semi-industrial grade antenna (since fully industrial-grade antennas must user glass fiber) and is recommended for any MIMO modem, router, and hotspot to drastically increase download and upload data speeds even in very fringe, low-signal areas. The WideAnt2-5G™ by WirEng® includes WirEng®'s marine-grade, fully stainless-steel MIMOMount™ for strict MIMO compliance and ease of installation. The recommended MIMO configuration is slanted (45 degrees) but all combinations are possible (vertical-vertical, horizontal-vertical, etc.). Extended 2-year warranty included. Patent pending.

Main Features

True MIMO and Directional (needs precise aiming)
All Cellular Bands Supported Worldwide
Drastically Increases Upload and Download Data Speeds
For All Routers, Hotspots, and Modems with Dual External Antenna
Stainless Steel Back Shield and Hardware On Each Element
Semi Industrial Grade (Anti-UV ABS)
24K Gold Plated N-Connector on Radome
Extended Operating Temperature Range of -25° to +85° C
High Input Power (up to 250 W Continuous)
Strong and Durable
IP67 Rating (Protected Against Dust, Strong Water Jets, and Waves)
UL94 V-0 Flammability Rating
USA and International Trademark Current. Patent Pending

Technical Specifications

Operating frequency range, MHz: 450 to 6000
Radiation type: Directional
Polarization: Vertical / Slanted / Horizontal
Nominal impedance, Ohm: 50
Acceptable impedance range, Ohm: 45 to 78
Signal gain, dBi: 2 x 7 to 14
VSWR: 1:1 to 1:1.5
IM3 intermodulation, dBc: -156
Radome material: UV-Treated ABS
Shield material: Stainless Steel
Internal elements main material: Alloy
Bolt/nuts/washers/lockers material: Stainless Steel
Color: Off White
Wind resistance, km/h: 215
Storage temperature, °C: -35 to 115
Environmental rating: EN 300 019-2-4
Connector type: Gold-Plated N-Type
Mount type: Pole
Flammability Rating: UL94 V-0
International Protection Marking: IP67
Weight, kg (pounds): 2.8 kg
(6.17 lbs)
Dimensions, cm (inches): 52 x 57 x 18 cm
(21 x 22.5 x 7 in)
Suitable markets: Worldwide
Warranty: 2 Years
